MULTI 600
FEATURES
-Digital speed display
-Less noise, less vibration
-Excellent durability
-Knee-control type
-Self-diagnosis function
-Auto-cruise function
-Variable speed control pedal (FS-60N)
-KNEE CONTROL TYPE l There is a desktop type that is controlled with a hand dial or foot pedal, and a type that is controlled with a knee by putting the tongue on the lower side of the work desk. The knee control type can respond sensitively to speed changes, so it is useful for detailed work.
-AUTO-CRUISE FUNTION l After setting the foot mode, if the foot (knee) pedal is maintained at a constant speed for 2 seconds, the Auto cruise mode is operated. Auto cruise mode is disengaged by pressing the pedal again or pressing the button again.
Contents
1-Control unit
2-Handpiece
3-Foot pedal
4-Mounting bracket
5-Handpiece stand
Specification
-MODEL MULTI600 (Control unit)
INPUT AC 100~120V, 50/60Hz AC 220~240V, 50/60Hz
WEIGHT 3,100g
DIMENSION W122 x D268 x H237
-MODEL SDE-BM50S1 (Handpiece)
SPEED 1,000-50,000 rpm
TORQUE 7.8 Ncm
WEIGHT 231 g
DIMENSION Ø27 x L160
-MODEL SDE-FS60N (Foot pedal)
WEIGHT 558 g
DIMENSION W170 x D110 x H58
