Emergency Transport Ventilator
PORT+ has been used throughout the globe as an incredibly reliable emergency transport ventilator.
The device is ideal for many other applications. Its applicability includes on-site emergency treatment, pre-hospital transport, inter-hospital transport, as well as intra-hospital transport. Whether the patient is an adult, child, or infant. PORT+ serves as a reliable life-supporting mechanism.
◆ Features & benefits :
- Complete Ventilation Modes
The device hosts six ventilation modes. Besides the conventional Volume-Controlled ventilation mode, it also has Pressure-Controlled ventilation mode, SIMV and CPAP modes. CPAP is a non-invasive ventilation mode.
- Ideal O2 Delivery
With its advanced technology, the range of FiO2 can be set from 40% to 100%.
- Electronically Controlled PEEP
It is very convenient and intuitive to set an exact PEEP to that the clinician desires.
- Proximal Flow Sensor
A proximal flow sensor is used in Heyer PORT+. Besides the pressure trigger, this machine can provide flow trigger.
- Power Supply Solution & Reliability Testing
The internal battery within the PORT+ has the capability of lasting up to 4.5 hours. Also, it can be used with both DC and AC Power. The PORT+ has passed many tests, such as both shock & vibration testing, as well as EMC
testing.
◆ Technical specifications :
- Treatment Mode : SIMV-V,SIMV-P,PSV,CPAP,Manual
- FiO2 : 40%-100%
- I:E Ratio : 4:1 - 1:10
- Tidal volume (VT) : 0-2000mL
- Pause time (Tpause) : 0-5 s
- Frequency (f) : FiO2
- PEEP : 0 - 30 cmH2O
- Flow trigger : 2-30 L/min
