Optics made of imported glass from Germany to reduce the optical aberration. All lenses are multi-coated, anti-reflective, and apochromatic.

The wide-field eyepieces are easily pushed into the binocular tube and have integrated eyecups with stepless adjustment. The eyepieces are perfectly suited for surgeons who wish to work with their eyeglasses on, as eye refraction can easily be adjusted with a high range of +/- 7D diopter.

The focal point separation of the pair lines can be adjusted in the range of 200mm to 450mm, allowing for easy focusing during operation.

Continuous zoom magnification is controlled through the adjustment knobs on both sides of the microscope head, Clinicians can single-handly adjust image magnification from 1.8x to 19.4x

binocular tube with PD knob (optional)

This MagPlus1.5 increase 50% magnification in the binocular

Backup light source for accidentally shutting down of the main LED Illumination.

The illuminance is higher than 170,000 Lux when the working distance at 250mm

Integrated Yellow & Green Filters, Illumination Filter

In addition to the two color filter of yellow and green, it is equipped with four pattern lighting range selector to reduce the burden to the eyes of the user.

Prevents premature curing of composite.

Improves detail visibility by enhancing the (Red free)contrast of tissue with a strong blood supply.

Optional recording system as option that has the ability to take a still image or a video and save all data onto an internal U disk. Review photos by mouse instantly

flash disk (optional)

Zumax introduces outstanding UHD resolution and superior color performance, *fidelity and economical. With outstanding performance, the camera outputs a whopping 3840/2160 resolution from HDMI interface with increased resolution up to 1800 TV lines.

iMovCloud™ Image Management (optional)

iMovCloud system has Single version, Intranet version and *Cloud version.

iMovCloud Single version is an advanced and fully integrated surgical image management system which based on Windows platform. It is an ideal choice for worldwide dental clinics. Together with Zumax microscope to collect videos and images, integrate four major management functions of clinics, doctors, patients and medical records to realize the sorting, analysis and documentation.

"Intranet version" service, which realize local network viewing, maintenance, management easily, is coming soon.

"Cloud version" service, which realize cloud viewing, cloud maintenance, cloud management, remote joint inspection and other functions.

Inclinable binoculars feature the widest range of any binoculars for user comfort and enhanced ergonomics for surgeons of all heights.

Accurate pupillary distance numbers have beefymarked on the knob; the dentist can conveniently and quickly adjust to any PD

This Balancing Arm assures an ultrasmooth, fluid, and perfect balance during repositioning of the microscope. Even when external accessories haves been attached, it balances the weight allowing smooth handling.

This function allows the user to remain in an upright viewing position, by changing the direction of the optic pod without changing the direction of the binocular head. this enhances user comfort and ergonomics.

(Adaptable to major camera brands, Iphone and some brands android phones)

Optional digital visualization accessories provide lossless live images or play-back to perform the steps of a procedure to patient's understanding and store the records for reviewing.

Multiple shooting methods by wireless footpedal set or the photo & video button on both handles.

Motorized Zoom System, with apochromatic 1:6 ratio 1.8x-20x with 12.5x eyepieces Magnification factor y=0.4X-2.4X

Variable Working Distance 200 mm ~450 mm

0°-180°Inclinable Binocular Tube with PD adjusting knob, f=170mm

55 mm~75 mm
