ID∅498 x L890 ㎜, Total Vol: 173ℓ (Usable Vol: 135ℓ), Material: STS 316L

50℃ ~ 60℃

35%, 50%, 60% of Hydrogen Peroxide Aqueous Solution

AC 220V 50/60Hz

3,300 W

490 Kg

The high-priced and precise medical devices and instruments which may be changed their properties and appearances unde a high temperature, pressure and humidity are sterilized without any change of material property under low temperature in a short time, therefore users are able to use them as ever for a longer time.

The operation efficiency of sterilizer and the turnover ratio of devices is much higher than EO gas sterilization because the sterilized devices are able to be used immediately without individual aeration process after sterilizing, therefore user needs not carry a large stock of instruments and the required cost can be reduced remarkably.

The low temperature hydrogen peroxide sterilization is harmless to the environment and there is no lurking dangers to the operators and patients because the hydrogen peroxide gases used as sterilant are changed into the oxygen and a little amounts of water after sterilizing.

Only a source of electric power is required in the place where installing the sterilizer and the additional facilities such as air compressor, drain piping and water source etc. are unnecessary, therefore the required space to install is rightly saved. User can operate the sterilizer easily by one touching on the color touch screen and monitor the progressing of a sterilization cycle in real time on it.

Before sterilization, the air in the chamber is sucked into the vaporizer and the hot air heated in the vaporizer is introduced into the chamber forcibly, and the cool air in the items to be sterilized and chamber is removed by the air circulation pump. This process is repeated for the set time. The sterilization effect is very advanced through this process because the hot air could be penetrated into the items or lumen of instruments to be sterilized and then they are preheated and dried.

Operating the sterilizer is very easy and convenient by one touching the graphic designed button on the large color touch screen, and the cycle progressing state is displayed in real time on the screen.

The sterilant(hydrogen peroxide solution), which is contained in the special designed bottle for conserving or handling, is injected into the chamber in a state of vapor automatically by having only to insert the sterilant bottle in the holder of injection unit conveniently and safely, therefore the safety for operator and workplace is guaranteed under any circumstances.

The sterilant penetration was improved remarkably in the phase of injection by adopting the vacuum pump with large capacity and deep vacuum performance and the sterility was enhanced by forming even plasma in the chamber in the phase of plasma.

The dry vacuum pump, which does not contain the oil functions to seal and lubricate for maintaining chamber vacuum, needs not oil replacement due to deterioration and the environmental pollution caused by the oil mist could be prevented. And the durability of pump is excellent because a trouble caused by the reaction between the exhaust gas and oil is not occurred.

It is harmless to the patients, health care providers and environment because the manganese dioxide catalyst filter installed in the end of exhaust line remove the residual toxic ingredient included in exhaust gas completely before discharging it in the air during chamber exhausting process.

At least 11 years of cycle execution records are automatically stored on the Flash memory of the control unit. The user can search and check the results of a cycle performed in the past by input the date performed or cycle count number on the touch screen, and print out the record by the built-in panel printer for using as an evidence data of sterilization quality. (optional specification)
