Technical specifications:-
Anode voltage 60–120 kV
Anode current 1–16 mA
Focal spot 0.5 mm, fixed anode
Image detector Flat panel
Image acquisition 200 / 360 degree rotation
Scan time 1–36 s
Typical reconstruction time 2–55 s
Maximum volume sizes
Volume size [cm]
Planmeca Viso G3
Maximum volume with a single scan:
Ø20 x 10
Planmeca Viso G5
Maximum volume with a single scan:
Ø20 x 10
Maximum volume with multiple vertical scans:
Ø20 x 17
Planmeca Viso G5 maximum volume size
Planmeca Viso G7
Maximum volume with a single scan:
Ø30 x 20
Maximum volume with multiple vertical scans:
Ø30 x 30
Dental programs
Volume size [cm]
Planmeca Viso G3
Tooth
Ø3 x 3 – Ø6 x 6
Teeth
Ø7 x 3 – Ø9 x 9
Jaw
Ø10 x 3 – Ø20 x 10
Planmeca Viso G5
Tooth
Ø3 x 3 – Ø6 x 6
Teeth
Ø7 x 3 – Ø9 x 9
Jaw
Ø10 x 3 – Ø20 x 10
Face
Ø14 x 13 – Ø20 x 17
Planmeca Viso G7
Tooth
Ø3 x 3 – Ø6 x 6
Teeth
Ø7 x 3 – Ø12 x 10
Jaw
Ø13 x 3 – Ø17 x 17
Face
Ø14 x 12 – Ø30 x 20
Skull
Ø26 x 30 – Ø30 x 30
ENT (Ear, Nose, Throat) programs
Volume size [cm]
Planmeca Viso G3
Nose
Ø7 x 5 – 9 x 9
Sinus
Ø10 x 10 – 20 x 10
Middle ear
Ø3 x 3 – 6 x 6
Temporal bone
Ø7 x 5 – 9 x 9
Airways
Ø9 x 8 – 11 x 10
Vertebrae
Ø9 x 8 – 11 x 10
Planmeca Viso G5
Nose
Ø7 x 5 – 9 x 9
Sinus
Ø10 x 11 – 20 x 15
Middle ear
Ø3 x 3 – 6 x 6
Temporal bone
Ø7 x 5 – 9 x 9
Airways
Ø9 x 8 – 11 x 10
Vertebrae
Ø9 x 8 – 11 x 10
Planmeca Viso G7
Nose
Ø7 x 5 – 12 x 10
Sinus
Ø10 x 10 – 17 x 20
Middle ear
Ø3 x 3 – 6 x 6
Temporal bone
Ø7 x 5 – 12 x 10
Airways
Ø8 x 8 – 10 x 14
Vertebrae
Ø8 x 8 – 10 x 14
Physical space requirements
Width 155 cm (61 in.)
Depth 154 cm (60.6 in.),
Height* 160-234 cm (63-92 in.)
Weight 165 kg
With cephalostat:
Width 216 cm (85 in.)
Depth 154 cm (60.6 in.)
Height* 160-234 cm (63-92 in.)
Weight 165 kg + 20 kg (ceph)
*The maximum height of the unit can be adjusted for offices with limited ceiling space.
