ICU Ventilator for Adult ,Pediatric ,Neonatal

Brand

Leistung Equipamentos Ltda

Model

LUFT 5

Manufacturing Country

Brazil

Quality Certificates

CE MARKING

ISO 13485

ISO 9001

Specification

LUFT 5

Essential for your team. Essential for your hospital.

High Performance ICU Pulmonary Ventilator

The LUFT5 is a modern, intelligent ventilator, specifically designed for Intensive Care Units (ICUs) and to make life easier for healthcare professionals. The device features conventional and advanced ventilation modes, as well as precise monitoring of ventilatory mechanics, providing greater safety for both patients and professionals.

-Chart analysis with freeze, zoom, cursors and points.

-Timed nebulization with insp. flow compensation and FIO2.

-17” LCD screen with capacitive touch and tilt adjustment.

-Elegant pedestal with large casters and smooth gliding.

-Advanced ventilation modes such as PRVC and VSV.

-Ventilatory mechanics for weaning such as IRRS, PIMAX, P0.1.

-Pressure booster to monitor esophageal or proximal pressure.

-Information on the resulting parameters when adjusting a variable.

-Screen information exportable via USB;

-Data transmission via HL7 protocol.

Complete in all parameters.

Differentiated in all configurations.

Better performance and maximum comfort during treatment

-Volumetric Capnography

It is a noninvasive test used to analyze the pattern of CO2 elimination as a function of expired volume. It allows estimation of the heterogeneity of pulmonary ventilation distribution resulting from functional and structural changes in the respiratory system.

-Stress Index

The stress index is calculated with minimal interference with the ventilatory cycle and results in an easily interpretable numerical value, providing a practical, safe, and effective analysis of the patient's ventilation. It is a useful measure of ventilatory mechanics for estimating the stress caused to the alveoli, whether by collapse or overdistension.

-PRVC

This is a dual-control ventilation mode. It combines the best of the assist/control volume and pressure ventilation modes, providing the volume set by the operator with the lowest possible inspiratory pressure. The flow waveform is free.

Special configurations to accurately monitor and safely treat

-Smart fan memorizes users' ventilation parameter settings after 10 uses.

-100% oxygen for up to 20 minutes, with automatic alarm silence.

-Dual processing, two boards and two processors for patient safety.

-Automatic altitude compensation.

-Adaptation of the patient interface or circuit change with recalibration without the need to turn off the equipment and maintaining the patient's history record;

-Automatic calculation of predicted weight and interface selection according to the patient;

-Internal barometric sensor for automatic altitude compensation up to 6000 meters above sea level;

-Configuration of monitored variables;

-50% descending flow curve;

-Gas measurement with BTPS corrections;

-Safety and convenience of dual-control ventilation modes for assisted and controlled ventilation;

-Complete analysis of the patient's ventilatory mechanics with comprehensive, fast and accurate resources;

-Auxiliary pressure input for pressure measurement, allowing greater monitoring.

Intuitive dynamic graphical interface to operate

Initial Configuration Screen

-Patient selection;

-Sex;

-Height;

-Automatic calculation of predicted weight;

-Ventilation level per mL/kg;

-Type of artificial airway;

-Humidification type;

-Line test;

-Circuit compliance measurement;

-Last patient function.

Operational Visualization

-Timer for activated maneuvers;

-Spontaneous/controlled cycle indicator;

-Battery charge level;

-Programming of ventilatory variables.

Adult / Pediatric

Customizable selection of up to

6 SIMULTANEOUS GRAPHICS

-Pressure / time;

-Flow / time;

-Volume / time;

-Volume/pressure;

-Flow/volume;

-Pressure/flow;

-P aux / time;

-ETCO2 / time;

-ETCO2 / volume.

Neonatal
