- Seamless Integration of Instrumentation and Reagents
Utilizes acridine ester direct chemiluminescence technology based on magnetic microparticles
Precision manufacturing and a robust traceability system
ensure accurate and reliable test results
- 1.1㎡ Compact Design
600 T/H High-Speed Analysis
9 min Quick Result
meeting emergency TAT requirements
- Effortless User Experience
Seamless Reagent Loading
Auto Maintenance, Hassle-Free
Flexible system configuration to optimize laboratory space
High-efficiency processing ensures timely delivery of test results
* Technical Specifications :
- Analyzer Type :
ully automated, random-access analyzer
- Working Principle :
Acridine ester chemiluminescence technology
- Throughput :
600 T/H
- First Result Time :
≤ 9min
- Sample Loading :
Track-based sample loading
- Sample Capacity :
Up to 50 samples simultaneously, expandable for continuous loading
- Automatic Retesting :
Supports auto-retest and priority emergency sample testing
- Sample Pipetting Range :
5μL~150μL
- Carryover Rate :
≤ 0.1ppm
- Sample Probe Features :
Liquid level detection, clog detection, volume tracking, collision protection
- Sample Types :
Serum, plasma, whole blood, urine, cerebrospinal fluid, and other bodily fluids
- Reagent Pipetting Range :
20μL~ 100μL
- Reagent Storage Temperature :
2℃ ~ 8℃
- Reagent Mixing :
Real-time online mixing
- Reaction Cups :
Auto-loading, continuous supply
- Reaction Types :
Compatible with common immunoassay modes
- Reaction Cup Mixing :
Non-contact mixing technology
- Magnetic Separation :
Quadruple magnetic separation technology
- Computer System :
Windows 10+ compatible
- Automatic Power On/Off :
User-defined scheduling
- Operating Temperature :
10℃~30℃
- Humidity Range :
30%~70%
- Atmospheric Pressure :
64kPa~106kPa
- Power Supply :
220V~, 50Hz, 2000VA
- Net Weight :
Approx. 454kg per unit
- Dimensions :
1156 × 969 × 1305 mm (L × W × H)
- Waste Disposal :
Standard direct drainage, optional waste container
- Pure Water Consumption :
90 L/H per module
- Standby Noise Level :
< 63 dB
