- SY-GW621 can be used for arthroscopy, ENT, PTED(percutaneous transforaminal endoscopic discectomy), cystoscope, percutaneous nephroscope, ventriculoscope, ductoscope, hysteroscopy, proctoscope, sigmoidoscope, urology resectoscope, plastic surgery endoscope, laparoscope, ductoscopy, breast implant endoscope, thoracoscopy, fiber nasopharyngoscope, fiber choledochoscopy, fber bronchoscope, fiber ureteroscope, APP hernia repair, lacrimal passage, minimally invasive varicose veins, etc.
- Brand: Shrek
- Product Type: Portable Endoscope Camera
- Warranty: Five years
Description :
1. Set screws use stainless steel material, so screws wont rust off and cause electrical short which extends service life of machine.
2. Baseboard of inner circuit board uses simple brass and protection cover, which is effective protection to antijamming of circuit and ground connection.
3. All signal cables use double-shielded, enhanced antijamming material which guarantee the antijamming capacity and long working life. The signal cable can stand 50,000 times bend by testing.
Parameter :
- LCD screen : 21”
- Aspect ration : 16:9
- Medical Monitor :Endoscopy Camera
- Image sensor : 1/1.8 CMOS
- Brightness : ODS adjustable
- Horizontal resolution : 1200TVL
- Scanning frequency : N:60HZ P:60HZ
- Scanning mode : Progressive scanning
- Surface temperatures : ≤60℃
- Medical Monitor : LED Light Source
- Light source : LED light
- Input power : 120VA
- Color temperature : 6000±500K
- Working life : >40,000hs
- Medical Monitor : HD Video Recorder
- Recording format : MP4
- Input signal : HDMI, CVBS
- Output signal : HDMI
